Amico ICU Bed

The new Amico ICU bed features a versatile design suitable for a wide range of patients. The ICU bed is differentiated by its enhanced chair position as well as its ergonomic and robust design. This product truly helps provide a more meaningful level of care to patients.

This bed has a battery back-up system to enable motion even when the bed is disconnected or during patient transport. The ICU bed also features LINAK™ DC actuators that offer a reliable yet silent motion for the bed’s electromechanical system.

Optional Features & Accessories:

• Pressure relief surfaces.
• Removable IV pole - 2 stage.
• IV hook.
• Side rail covers.
• Overbed table.
• Brake not set alarm.
• Communication to nurse call systems.
• Oxygen tank holder.
• Bed Exit Alarm.
• Fowler Angle Indicator.
• Hand pendant controls.
• 3-zone Bed Exit Alarm.

Key Features:

• 550 lbs (250 kg) weight capacity.
• Standard fifth wheel for improved mobility.

• 21" (53 cm) low height.
• Storage area in base for two oxygen E-cylinder tanks and belongings.
• Radiolucent fowler section.
• Dual brake pedal mechanism.
• Adjustable knee gatch for enhanced comfort.
• Fold-down side rails.
• 8" (20 cm) wheel casters.
• Pressure relief surfaces.

Standard Features:

• LINAK™ DC Actuators.
• Modular battery backup.
• LED night light.
• Four IV pole sockets.
• Four integrated roller bumpers.
• Metal litter deck.
• X-ray cassette holder.
• CPR release system.
• Trendelenburg and reverse Trendelenburg.
• Patient controls on inner side rails.
• Flat litter deck for compatibility with standard patient surfaces.
• Adjustable bed height.
• Adjustable foot extension.
• Adjustable litter with chair position.
• Integrated Digital Scale.
• Patient Exit Alarm
• Scale and Fowler Angle Indicator on Side rail.
• Foley Bag Holder.
• Integrated push handles.
• 5th wheel for improved mobility.

Specifications:

• Dimensions: Length Retracted: 83" (211 cm), Length Extended: 91" (231 cm), Width - Side rails up: 42" (107 cm), Width - Side rails down: 38" (96.5 cm).
  Patient Surface: Retracted: 32" x 71" (81 cm x 180 cm), Extended: 32" x 79" (81 cm x 201 cm).
• Height Range (to the surface of the litter): High: 38" (96.5 cm), Low: 5" (52 cm).
• Litter Positioning: Trendelenburg/Reverse Trendelenburg: ± 18°, Backrest: 0°- 70°, Knee Gatch: 0°- 21°.
• Weight Capacity: 550 lbs (250 kg).
  Caster Diameter: 6" (15 cm).

• Volts: 120 VAC, 220 VAC.

• Ampere Rating: 7.5 A, 4.0 A.

• Current Leakage: <300 µA.
• Frequency: 50 - 60 Hz.
• Plug Listing: Hospital Grade.
